Fishman Matrix Infinity Mic Blend Undersaddle Pickup System | No Limit Guitar Co, Idaho Falls
The Fishman Matrix Infinity Mic Blend combines the company's best-selling Acoustic Matrix undersaddle pickup with a multi-position condenser microphone to deliver exceptional tonal versatility for acoustic guitarists. This professional-grade system captures both the direct string vibration and the natural resonance of your guitar's body, providing studio-quality sound reproduction for live performance and recording. Ideal for intermediate to professional players who demand transparent, natural amplified tone with complete control over their acoustic sound.
Product Overview
The Matrix Infinity Mic Blend features Fishman's renowned undersaddle piezo pickup paired with a cardioid condenser capsule that works together to capture your guitar's full sonic character. The narrow-profile undersaddle transducer installs beneath your saddle to pick up string vibration directly, while the internally-mounted microphone captures the air movement and body resonance that define your instrument's unique voice. The system's black finish blends seamlessly into your guitar's soundhole.
The preamp offers intuitive soundhole-mounted controls including Volume, Tone, and a dedicated Blend knob that allows you to mix the pickup and microphone signals to taste. Whether you prefer the clarity and feedback resistance of the pickup or the natural warmth of the microphone, the Blend control puts the perfect balance at your fingertips. The unique Tone control provides a scooped EQ curve that cuts mids while simultaneously boosting treble and bass frequencies.
Advanced features include a two-position voicing switch that lets you choose between flat frequency response or rich bass boost with extended low-end response, allowing you to optimize the system for your guitar's body size and playing situation. The system operates on a single 9-volt battery that provides approximately 90 hours of continuous use, and offers both mono and stereo output options depending on your cable choice.
Ideal For
- Performing singer-songwriters who need reliable, feedback-resistant amplified tone for live venues
- Studio musicians seeking natural acoustic reproduction with minimal coloration for recording sessions
- Fingerstyle players demanding clarity across all frequencies and dynamic expression
- Touring professionals requiring versatile tonal options for different performance environments
- Acoustic guitarists at No Limit Guitar Co in Idaho Falls looking to upgrade from basic pickup systems
Key Features
Dual-Source Pickup System
The combination of Fishman's Acoustic Matrix undersaddle pickup with a cardioid condenser microphone provides the best of both worlds—the clarity and feedback resistance of a piezo pickup with the natural warmth and air of a microphone. This hybrid approach captures your guitar's complete sonic signature from string attack to body resonance.
Intuitive Blend Control
The soundhole-mounted Blend control makes it simple to find your ideal mix of pickup and microphone signals in real-time. Dial in more pickup for high-volume situations where feedback is a concern, or increase the microphone presence for intimate performances where natural tone is paramount.
Flexible Voicing Options
A two-position voicing switch lets you select between flat frequency response for balanced, transparent tone, or bass boost mode with extended low-end for fuller sound from smaller-bodied guitars. An internal dip switch provides additional bass enhancement options for ultimate tonal customization.
Scooped Tone Control
The unique Tone control offers a distinctive EQ profile that simultaneously cuts midrange frequencies while boosting treble and bass. This voiced approach helps your acoustic guitar cut through a band mix without sounding harsh or losing its fundamental warmth.
Professional Installation Features
The system includes solderless connections for reliable, easy installation along with mounting tools and a positioning guide for the condenser microphone. While professional installation is recommended for best results, the thoughtful design makes the installation process straightforward for qualified guitar technicians.
What's Included
- Fishman Matrix Infinity Mic Blend Pickup System
- Acoustic Matrix undersaddle pickup (3/32" narrow saddle profile)
- Multi-position cardioid condenser microphone capsule
- Soundhole-mounted preamp with Volume, Tone, Blend, and Voicing controls
- Microphone mounting tool and positioning guide
- Installation hardware and battery clip
- Manufacturer's warranty
- Professional installation recommended (available at No Limit Guitar Co)
Technical Specifications
| Specification | Details |
|---|---|
| Instrument Type | Acoustic and Classical Guitar |
| Pickup Types | Piezo Undersaddle, Cardioid Condenser Microphone |
| Position | Bridge Plate, Undersaddle (3/32" Saddle) |
| Active/Passive | Active |
| Built-in Preamp | Yes |
| Controls | Volume, Tone (flat to scooped), Blend, Voicing Switch |
| Additional Features | Bass Boost (internal dip switch), Mono/Stereo Output |
| Microphone Type | Multi-position Cardioid Condenser Capsule |
| Output Options | Mono or Stereo (cable-dependent) |
| Power Source | 1 x 9V Battery |
| Battery Life | Approximately 90 hours |
| Saddle Compatibility | Narrow (3/32" width) |
| Manufacturer Part Number | PRO-MAN-MBV |
Get Your Hands on This Acoustic Pickup System Today
Experience the transparent, natural tone of the Fishman Matrix Infinity Mic Blend at No Limit Guitar Co in Idaho Falls, where our knowledgeable staff can demonstrate the system's capabilities and discuss professional installation options. Whether you're upgrading your current acoustic guitar or adding amplification to a treasured instrument, this versatile pickup system delivers studio-quality sound for stage and recording. Contact us today to learn more about the Matrix Infinity Mic Blend or visit our Idaho Falls guitar store to explore our complete selection of acoustic guitar electronics and accessories.
